2 Characteristics of the Ethernet CPs
A-48
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
2.3 Attachment Variants
Below, you will see several typical possible attachments.
For further information on attachment options and Ethernet structures, refer to the
Ethernet network manual /9/. For ordering data and information on further
components, please refer to the IK PI catalog.
2.3.1 Electrical Attachment
The CP can be attached to Industrial Ethernet as follows:
Transceiver with AUI attachment
*)
CP
Transceiver cable
drop cable 727-1
CP
Transceiver
Figure 2-3
The CP provides the power supply required for the transceiver.
*)
The AUI attachment does not exist on all CPs for S7-300/S7-400; Please
note the information in the manual.
