5.2 Reading RFID data from the transponder
The table below lists instructions for reading RFID data from the transponder. HMI
screen "IOL_Station_READ" is used here.
Table 5-1
No.
Action
1.
In the input fields "Timer" and "Length" you enter (an "Offset" if desired) the
values relevant for reading the RFID data. (see Chapter 2.2.1)
2.
Click on the "READ" button.
3.
The read RFID data is available to you in the Read Data area.
