2 Solution
Read/write data with IO-Link
Entry ID: 73565887, V3.4, 06/2022
12
© Siemens AG
2022 All rights reserved
2.3 Hardware and software components
2.3.1 Validity
• all S7-1500 CPUs from the SIMATIC product range
• STEP 7 V17
• WinCC V17
• reader of the RF200 (V1.1) family with IO-Link interface
2.3.2 Components used
The application was created with the following components:
Hardware components
Table 2-5
Component
No.
Article number
Note
SIMATIC S7-1500
CPU 1513-1PN
1
6ES7 513-1AL01-0AB0
Alternatively, any other
SIMATIC S7-1500 with PN
interface compatible with the
CP can also be used.
SIMATIC PM 1507
24 V
1
6EP1332-4BA00
Alternatively, any other
voltage supply can also be
used.
ET 200SP
IM 155-6PN HF
1
6ES7155-6AU00-0CN0
Another IO-Link master can
also be used.
CM 4xIO-Link
1
6ES7137-6BD00-0BA0
SIMATIC RF220R
IOL
1
6GT2821-2BC32
Another RF200 IO-Link reader
(V1.0) can also be used.
Reader cable
1
6GT2891-0LH50
When using alternative IO-
Link master, the respectively
suitable cables are
documented in \10\.
RF Transponder
n
MDS Dxyz
Alternatively, another
transponder type can also be
used.
Note
A SIMATIC Basic Panel KTP1000 is not absolutely necessary. For simulating the
user interface, the PC runtime of STEP 7 V17 will be used.
