3 Mode of Operation
Read/write data with IO-Link
Entry ID: 73565887, V3.4, 06/2022
20
© Siemens AG
2022 All rights reserved
3.2.3 Error and status display
For error diagnostics, the function blocks "IolReadAnt" (FB3) and "IolWriteAnt"
(FB5) have one STATUS output each. By reading the STATUS output of the
function block you receive information on
• Error messages of the IolReadAnt function block (FB3) and the function blocks
of the library
• Error messages of the connected RF200 IO-Link reader.
Note
If there are error messages, the received data is invalid.
Error messages of the user program
The table below shows error messages of the function blocks "IolReadAnt" (FB3),
"IolWriteAnt" (FB5) and the function blocks of library ("LIOL_Antenna",
"LIOL_Read", "LIOL_Write").
Table 3-9
STATUS
Description
Remedy
16#00018101
The transponder has left the field during the
read process.
Restart process
16#00018102
The previous job has not been completed yet.
The job is finished at the next possible time.
Restart process
16#00018103
No transponder was detected in the reader’s
field within the specified time.
Restart process
16#00018104
The given length is smaller than 28.
Specify a length of a
minimum of 28.
16#000180xy
16#000187xy
16#000185xy
16#00018xyy
Error messages of the extended instructions
"BLKMOV", "DPRD_DAT" and "DPWR_DAT".
Online help in STEP 7
16#001100xx
Error messages of the connected reader
See below.
Error messages of the RF200 IO-Link reader
The error of the connected reader can be determined as follows:
• directly on the reader by counting the flash pattern of the red error LED
• via the STATUS parameter (16#001100xx)
A detailed overview of these errors is available in the manual "RFID systems
SIMATIC RF200 IO-Link" (see \5\, Chapter 7).
