Installation and Set-up
2-3
S5 UniLink Adapter Installation and Operation
For the S5 UniLink Adapter to establish communications with the CP 525
module, the following prerequisites must be met. Use the PG programmer to
load these parameters.
• The STEP 5 user program in the CPU must include the data handling
blocks
SEND ALL and RECEIVE ALL.
• The CP 525 user program of the CP module must include the RK 512
Interpreter and the 3964R Transfer Procedure.
NOTE: Remember to program the communications parameters (9600 or
19,200 baud, 8 bits, even parity, and 1 stop bit) in the CP 525 module.
No jobs in the CP module job block are required for the connection to the
S5 UniLink Adapter.
For more information on setting up the CP 525 module and the controller
CPU, refer to the CP 525 Communications Processor manuals.
Programming the
CP 525
