Installation and Set-up
2-2
S5 UniLink Adapter Installation and Operation
2.1 Overview
This chapter provides an introduction to the operation and set-up of the
S5 UniLink Adapter.
During normal operation, requests are sent over the TIWAY network to the
S5 UniLink Adapter; thus it functions in the same manner as any other
secondary in the network. Appendix B lists the TIWAY primitives supported
by the S5 Adapter.
The majority of requests issued to the S5 Adapter are to obtain memory
locations from the S5 PLC. Appendix A lists the memory translations from
the TI505 (TT types) to the S5 memory types.
To connect and set up the S5 UniLink Adapter properly, follow these steps.
Run appropriate cabling.
Program the CP 525 Communications Processor and the S5 PLC CPU.
Set the Dipswitches in the S5 UniLink Adapter.
Install the S5 Personality Interface Module (PIM).
Power Up the S5 UniLink Adapter.
Figure 2-1 Main Steps for Setting up the S5 UniLink Adapter
The S5 UniLink
Adapter as a TIWAY
Secondary
Setting Up the
S5 UniLink Adapter
To Next Page
