7.3 Spare parts for SIMODRIVE POSMO A
7-259
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
The drive unit is replaced as follows:
Caution
The positioning motor must be brought into a no–voltage condition
before the drive unit is replaced.
1. Remove the connection cover
– Tool Screwdriver, Size 4 (1.0 x 6.5)
2. Release the four screws retaining the drive unit
– Tool Allen key SW 3
3. Remove the old drive unit
4. Mount the new drive unit
5. Tighten the four screws retaining the drive unit
– Tool Allen key SW 3
– Tighten the screws diagonally
– Tightening torque 2.5 – 3 Nm
6. Locate the connection cover and tighten the screws
– Tool Screwdriver, Size 4 (1.0 x 6.5)
7. Load the parameter set
The parameter set provided must be downloaded into the new drive
unit from the old drive unit.
8. Test the positioning motor
Note
For the separate version where the motor and drive unit are separated,
the installation sequence when replacing the drive unit is the same.
However, in this case, the drive unit is removed from the extension set
”separate version”.
The spare drive unit has the following Order No:
Order No. (MLFB): 6SN2157–0AA01–0BA1
Refer to Chapter 7.1 under ”Address to return the positioning motor” for
the address of the regional spare parts department that is responsible
for you.
