Siemens SIMODRIVE POSMO A User Manual

7
7.3 Spare parts for SIMODRIVE POSMO A
7-261
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
The connection module is replaced as follows:
Caution
The positioning motor must be brought into a no–voltage condition
before the connection module is replaced.
1. Release the power and signal cables (refer to Chapter 2.3.1)
2. Remove the connection cover
– Tool Screwdriver, Size 4 (1.0 x 6.5)
3. Release the four screws retaining the connection module
– Tool Screwdriver Torx T10
4. Mount the new connection module to the drive unit
5. Tighten the four screws retaining the drive unit
– Tool Screwdriver Torx T10
– Tightening torque max. 1.8 Nm
6. Locate the connection cover and tighten the screws
– Tool Screwdriver, Size 4 (1,0 x 6,5)
7. Connect the power and signal cables (refer to Chapter 2.3.1)
8. Test the positioning motor
J
How do you
replace the
connection
module?
7 Installation and Service
04.0110.07
