3.2 Commissioning the DP master
3-84
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
The information provided in the following text provides you with some
basic information and instructions on how to handle the parameterizing
and start–up tool ”SimoCom A”.
Table 3-1 Information on ”SimoCom A”
Function
Description
Tasks
that can be executed
using ”SimoCom A”
S Check the wiring (go into the Online Help: connection diagrams)
S Establish a connection to the drive to be parameterized
S Change the parameters
– The essential parameters are changed, dialog–prompted
– You can change all of the parameters using the expert list
S Traverse the axis
S Diagnose the drive status
– Obtain an overview of all of the connected drives and their status
– Detect the connected hardware
– Display the terminal status
– Alarms and information on how they can be removed
S Carry–out diagnostics
– Parameterize test sockets (DAU1, DAU2). Selected signals in the drive
can be routed to the test sockets for measurement with an oscilloscope.
S Save the results
– Save the parameters in the drive FEPROM
– Save the parameters in a file/open a file
– Print the parameters
S Compare parameter sets
This allows the difference between 2 parameters sets to be identified.
S Initialize the drive
The drive can be initialized using this function. It is then necessary to config-
ure a drive.
S Load the factory setting
The status of a drive when originally shipped can be established using this
function.
S Generate a user parameter list.
The user can include a parameter in this list. This list has the same function-
ality as the expert list.
Language Menu ”Option/Settings/Language”
Browser The browser (the lefthand window) can be set to the following areas via the
lower buttons:
S Parameter (Par)
S Operator control (OpCo)
S Diagnostics (Diag)
Close/open the browser: Menu ”Options/settings/browser”
Information on
”SimoCom A”
02.99
