3.2 Commissioning the DP master
3-87
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
Table 3-1 Information on ”SimoCom A”, continued
Function Description
Expert list You can influence the complete parameter set of a drive using the expert list,
i.e. you can individually change each parameter.
In this case, the operator is not additionally supported by dialog boxes.
Parameterization using the expert list should only be used in exceptional cases.
Operating information:
S Call: Menu ”Start–up/Additional parameters/Expert list”
S The standard value and the value limits for the actual parameters are dis-
played via the tooltip.
S Modified values only become effective after pressing the Enter key or if
another parameter was selected. Values which are not active have a yellow
background.
S Expert list selected ––> Menu ”List” or the righthand mouse key
The following functions can be executed in this window:
– Display filter: Here, you have the possibility of selecting as to which data
should appear in the expert list: e.g. all data or only the controller data.
– Search: Using F3 (or menu ”List/Search), you can search for specific
terminals. For instance, you can search for ”temp” if you wish to know
the value for the electronics temperature.
– Bit–coded values: With the cursor, go to the line and press F4 (or menu
”List/bit value”). You then obtain a plain text display of the individual bits
and can select these at a click of the mouse.
Data transfer Also here, the program attempts to ”think with you”:
If you are presently working on a drive and select File/Download into drive” then
the program assumes that you wish to download a file, still to be selected, into
this particular drive.
If a file is presently open, then the program assumes that using the same com-
mand, you wish to download this open data set into a drive still to be selected.
If these assumptions are not applicable, then you can always undo by cancel-
ing.
Integrated help The ”SimoCom A” tool is equipped with an integrated help function which sup-
ports you when using the ”SimoCom A” and the ”SIMODRIVE POSMO A” drive.
You can call the help function for ”SimoCom A”:
S Using the menu ”Help/help subjects ...” or
S By pressing the ”Help” button or
S By pressing key ”F1”
3 Commissioning
02.99
