6.6.1 Conductor connection type shaft height 280
Terminal board Shaft height 280 Shaft height 280 + R50
M10 M12
TB4N01 TB4N61 TB4Q01 TB4Q61
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Connection
with cable
lug
DIN 46234
2
1
3
120 95 120 95 185 120 185 120
Connection
with cable
lug
DIN 46234
with termi‐
nal stud for
cable con‐
nection
2
1
3
Connection
with clamp
terminal for
connections
without ca‐
ble lug
2
1
3
Connecting bar
Line connecting cable
Motor connecting cable
Electrical connection
6.6Conductor connection
1LE5, 1PC4 shaft heights 280 ... 355
74 Operating Instructions, 11/2022, A5E41454666A
