6.6.2 Conductor connection type shaft height 315 ... 355
Terminal board Shaft height 315 Shaft height 355
Shaft height 315 + R50
*)
M12 M16
TB3Q01 TB3Q61 TB3R01 TB3R61
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Max.
conduc‐
tor
cross-
section
mm²
Recom‐
mended
conduc‐
tor
cross-
section
mm²
Connection
with cable
lug
DIN 46234
2
1
3
185 120 240 185 300 240 300 240
Connection
with cable
lug
DIN 46234
with termi‐
nal stud for
cable con‐
nection
2
1
3
300
*)
240
*)
300
*)
240
*)
Connection
with clamp
terminal for
connections
without ca‐
ble lug
2
1
3
① Connecting bar
② Line connecting cable
③ Motor connecting cable
Electrical connection
6.6Conductor connection
1LE5, 1PC4 shaft heights 280 ... 355
Operating Instructions, 11/2022, A5E41454666A 75
