10.9.5 1LE5, 1PC4 shaft height 315
Overall length 1LE5/1PC4_ _ _ - _ _ _ 0, 2, 4, 5, 6
*)
*)
6-pole, 8-pole
The overall length corresponds to the 11th position of the machine type on the rating plate.
Spare parts
10.9Exploded drawings
1LE5, 1PC4 shaft heights 280 ... 355
124 Operating Instructions, 11/2022, A5E41454666A
