10.8 Standardized parts
Table 10-2 Purchase standard parts according to dimensions, material and surface properties through normal commercial
channels.
No Standard Picture No Standard Picture
6.02 DIN 471
6.75 EN ISO 4026
4.04 DIN 580 5.55 EN ISO 4032
1.60
6.10
DIN 625 4.39
5.60
5.79
5.89
EN ISO 4017
1.30
1.49
5.46
5.49
5.60
6.29
7.49
EN ISO 4762
3.38 DIN 6885
5.94 EN ISO 7045
5.18
5.36
EN ISO 7089
Spare parts
10.8Standardized parts
1LE5, 1PC4 shaft heights 280 ... 355
Operating Instructions, 11/2022, A5E41454666A 119
