Motor type No. of cores x cross‐
section in mm
2
Min. bending radius
"R1" in mm
1
)
Connector size
2
)
1FW6230-xxB20-2Pxx 3 x (1 x 35) + M10 f. PE
(1x25)*)
48.3 -
1FW6230-xxB20-0Wxx 3 x (1 x 70) + M10 f. PE
(1x35)*)
61.5 -
1FW6290-xxB07-5Gxx 4x16.0 89.2 1.5
1FW6290-xxB07-0Lxx 3x(1x35)+1x25 R(35) = 48.3
R(25) = 40.5
-
1FW6290-xxB07-2Pxx 3x(1x70)+1x35 R(70) = 61.5
R(35) = 48.3
-
1FW6290-xxB11-5Gxx 4x16.0 89.2 1.5
1FW6290-xxB11-7Axx 4x16.0 89.2 1.5
1FW6290-xxB11-0Lxx 3x(1x35)+1x25 R(35) = 48.3
R(25) = 40.5
-
1FW6290-xxB11-2Pxx 3x(1x70)+1x35 R(70) = 61.5
R(35) = 48.3
-
1FW6290-xxB15-7Axx 4x16.0 89.2 1.5
1FW6290-xxB15-0Lxx 3x(1x35)+1x25 R(35) = 48.3
R(25) = 40.5
-
1FW6290-xxB15-2Pxx 3x(1x70)+1x35 R(70) = 61.5
R(35) = 48.3
-
1FW6290-xxB20-0Lxx 3x(1x35)+1x25 R(35) = 48.3
R(25) = 40.5
-
1FW6290-xxB20-2Pxx 3x(1x70)+1x35 R(70) = 61.5
R(35) = 48.3
-
1
) Power cable xed;
2
) Applies to motors with connector
*) PE cable to be connected separately; not included in scope of delivery
Table 6-2 Specications for the signal cable on the stator
Motor type No. of cores (signal cores) x cross‐
section + no. of cores (PE) x cross-sec‐
tion in mm
2
Min. bending
radius in mm
1
)
Connector
size
2
)
1FW6xxx-xxxxx-xxxx 6 x 0.5 + 1 x 1.0 50 M17
1
) Signal cable xed;
2
) Applies to motors with connector
