Materials used in the cooling circuits of torque motors
Table 3-8 Materials in the cooling circuits of torque motors (not including the material used for the connections)
Cooling jacket Integrated cooling
(main cooler)
Integrated cooling
(precision cooler)
Cooling connection adapter
1FW6090, 1FW6130:
EN AW-5083
(EN573-3)
Viton® (FPM) gasket
1FW615x
*)
:
S355J2G3
(EN10025)
Viton® (FPM) gasket
1FW6050, 1FW6060:
X10CrNiS18-9
(DIN17440)
SF-Cu
(DIN17671)
Viton® (FPM) gasket
1FW6160, 1FW619x
*)
,
1FW623x
*)
, 1FW6290:
X6CrNiTi18-10
(EN10088)
SF-Cu
(DIN17671)
CW617N
(DINEN12449 /
DINEN12167)
Viton® (FPM) gasket
Ag 102
(EN 1045) +
welding 󹪞ux EN1045-
FH10
1FW6160, 1FW619x
*)
,
1FW623x
*)
, 1FW6290:
X6CrNiTi18-10
(EN10088)
SF-Cu
(DIN 17671)
CW617N
(DINEN12449)
Viton® (FPM) gasket
1FW6160, 1FW619x
*)
,
1FW623x
*)
, 1FW6290:
CW617N
(DINEN12449 /
DINEN12167)
Viton® (FPM) gasket
*)
Applicable for the corresponding frame size, also for 1FW6 High Speed built-in torque motors
NOTICE
Corrosion as a result of unsuitable materials used to connect the cooler
Corrosion damage can occur if you use unsuitable materials to connect to the cooler.
We recommend that you use brass or stainless steel 󹪝ttings when connecting the cooler.
Description
3.4Design
1FW6 built-in torque motors
Operating Instructions, 09/2022, A5E52220812B AA 47
