1.6 CompactFlash card
SIMOTION D410-2
Manual, 02/2012
21
The CompactFlash card is supplied in a bootable format with the latest SIMOTION Kernel
and drive software.
CompactFlash card type plate
The following figure shows all the information included on the type plate of the
CompactFlash card (CF card).
+:VHULDOQXPEHU&RPSDFW)ODVKFDUG
/LVWRIWKH=RSWLRQV
/LFHQVHVRQ&RPSDFW)ODVKFDUGRQ
GHOLYHU\
0DUNLQJIRUGLUHFWLRQRILQVHUWLRQ
RIWKH&RPSDFW)ODVKFDUG
2UGHUQXPEHU
'HOLYHU\QRWHQXPEHU
8QLTXHQXPEHU
'DWD0DWUL[&RGH
LQFOXGLQJRUGHUQXPEHU
'DWHRIPDQXIDFWXUH
3URGXFWDQGYHUVLRQGHVLJQDWLRQ
FDUGFDSDFLW\ERRWORDGHUYHUVLRQ
,GHQWLILHUIRU&RPSDFW)ODVKFDUGZLWK=
RSWLRQ
9HUVLRQGLJLW
*%%RRWORDGHU9
6,1$0,&69
6,027,21'9
= 07

Figure 1-8 CompactFlash card
Pre-installed runtime licenses
The pre-installed licenses are provided as Z option on the label below the order number.
Example with Z option for D410-2 MultiAxes package + two TControl licenses:
6AU1400-1PA22-0AA0-Z
Z=M41+T02
A maximum of seven different Z options are printed on the type plate of the
CompactFlash card. When there are more than seven different Z options, the text "Z = see
delivery order" is printed on the CompactFlash card in place of the Z option.
