Technical data
4.4 Interfaces and performance features
SIMOTION D410-2
Manual, 02/2012
63
CompactFlash card
Table 4- 5 CompactFlash card
Memory capacity 1 GB (order no. 6AU1400-1PA22-0AA0)
Weight 10 g
Mounting plate
Table 4- 6 Mounting plate data
Dimensions W x H x D 74.5 x 236 x 36.5 mm
Weight
- Without packaging
- With packaging
380 g
450 g
Further technical data
For further technical data such as the max. number of online connections, HMI devices that
can be used as well as a list of tasks available in the execution system, see the function
overview in the
PM 21 Catalog , Motion Control SIMOTION , SINAMICS S120 and motors for
production machines
.
4.4 Interfaces and performance features
4.4.1 PLC and motion control performance
Number of axes and clock cycles
Table 4- 7 Maximum number of axes and minimum cycles for SIMOTION D410-2
PLC and motion control performance
Maximum number of axes 8 axes
1)
Minimum PROFIBUS cycle 0.5 ms PROFIBUS Integrated
1 ms PROFIBUS external
Minimum servo/interpolator cycle clock 0.5 ms
(1 ms when using the TO axis and the integrated drive
control)
1)
Path interpolation is not supported for V4.3.
