Siemens SIMOTION D410-2 User Manual

Technical data
4.3 System data, connection values, dimensions and weight
SIMOTION D410-2
62 Manual, 02/2012
4.3 System data, connection values, dimensions and weight
General technical data
The SIMOTION D410-2 has an integrated fan.
Table 4- 3 General technical data
Dimensions and weight
Dimensions W x H x D 73 x 186.8 x 74.2 mm
Weight
• Without packaging
• With packaging
• 830 g
• 1000 g
Electrical connection values
Power supply 24 VDC (permissible range: 20,4 ... 28.8 V)
Ripple Max. 5% at 24 VDC
Non-periodic overvoltage Max. 35 VDC
(Condition: Max. 500 ms, 50 s recovery time, max.
10 results/h)
Current consumption, typically
1)
< 0.8 A
Starting current, typically
1)
3.0 A
Power loss, typically
1)
< 20 W
1)
With no load on I/Os and no 24 V supply via DRIVE-CLiQ or PROFIBUS interface
Memory
Table 4- 4 Technical data for memory
RAM (Random Access Memory) At least 40 MB
RAM disk (load memory) At least 25 MB
Retentive memory
(retain variables)
At least 25 KB
Persistent memory
(user data on 1 GB CompactFlash card)
300 MB
Work memory for Java applications 20 MB
Non-volatile data buffering
buffer time, min. Unlimited (maintenance-free backup)
Memory for system data
Diagnostic buffer (protected against power
failure)
100 messages (SIMOTION)
100 messages (SINAMICS Integrated)
