Interfaces
3.3 PROFIBUS DP interfaces
SIMOTION D410-2
36 Manual, 02/2012
Additional information
For information on the components that can be connected via DRIVE-CLiQ (setup,
connection, configuration, etc.) see
●
SINAMICS S120 Control Units and Additional System Components Manual
●
SINAMICS S120 for AC Drives Manual
●
SINAMICS S120 Commissioning Manual
●
SINAMICS S120 Safety Integrated Function Manual
●
TM15/TM17 High Feature SIMOTION Terminal Modules Commissioning Manual
●
SIMOTION Terminal Modules TM15 / TM17 Manual
3.3 PROFIBUS DP interfaces
Properties
SIMOTION D410-2 DP provides two interfaces for connection on the PROFIBUS DP:
● PROFIBUS DP/MPI interface (X21)
● PROFIBUS DP interface (X24)
The interfaces can be run asynchronously or isochronously, equidistant.
SIMOTION D410-2 DP includes master and I-slave functionality.
Interface characteristics
Table 3- 6 X21 and X24 interfaces
Characteristics Type
Connector type 9-pin sub-D socket
Cable type PROFIBUS cable
Max. cable length 100 m at 12 Mbit/s
Maximum data rate 12 Mbit/s
