Interfaces
3.2 DRIVE-CLiQ interface
SIMOTION D410-2
Manual, 02/2012
35
Connectable devices
The following table contains the components that can communicate with SIMOTION D410-2
via the DRIVE-CLiQ interface. Note the max. number of nodes that can be connected to the
DRIVE-CLiQ!
Note
Note also the topology rules of the SINAMICS S120, see
SINAMICS S120
Function Manual,
Section "Rules for wiring with DRIVE-CLiQ".
Table 3- 5 DRIVE-CLiQ connection topology
Component Max. number of connectable nodes
Drive Max. one drive from the following:
• PM340 Blocksize Power Module (D410-2 directly snapped on)
• PM340 Blocksize Power Module (D410-2 issued via CUA31/CUA32)
• Power Module Chassis AC/AC
Motors with DRIVE-CLiQ interface,
DRIVE-CLiQ encoder and SMx sensor
modules
Max. five encoder systems via DRIVE-CLiQ:
• Sensor modules (SMx) for transferring an encoder signal to DRIVE-CLiQ
• Encoders with a DRIVE-CLiQ interface
• Motors with DRIVE-CLiQ interface
You require a DRIVE-CLiQ hub module (DMC20/DME20) or a CUA32 to
connect more than one encoder system via DRIVE-CLiQ.
Terminal expansion modules Max. eight terminal modules (TM), of which
• Maximum three TM15, TM17 High Feature, TM41
• Maximum eight TM15 DI/DO, TM31
• Maximum one TM54F
DRIVE-CLiQ hub module 20
(DMC20/DME20)
Max. one DMC20 or DME20
Note:
Because an SMx sensor module and a motor with a DRIVE-CLiQ interface have
only one DRIVE-CLiQ interface, a DMC20/DME20 must be used with a second
encoder on the DRIVE-CLiQ. If a CUA31/CUA32 is used, the DMC20/DME20 is
not required. Alternatively, a second encoder can also be connected via the X23
encoder interface.
