Interfaces
3.7 Ethernet interface
SIMOTION D410-2
56 Manual, 02/2012
Interface characteristics
Table 3- 21 X127 interface
Characteristic Type
Connector type RJ45 socket connector
Cable type Industrial Ethernet cable
Maximum cable
length
100 m
Autocrossing Yes, i.e. crossed and uncrossed cables can be used
Blanking cover for Ethernet interface included in the scope of delivery;
blanking cover (50 units), order number: 6SL3066-4CA00-0AA0
Interface assignment
Table 3- 22 X127 interface assignment
Representation Pin Signal name Signal type Meaning
1 TXP Output Ethernet transmit differential signal
2 TXN Output Ethernet transmit differential signal
3 RXP Input Ethernet receive differential signal
4 - - Reserved, do not use
5 - - Reserved, do not use
6 RXN Input Ethernet receive differential signal
7 - - Reserved, do not use
8 - - Reserved, do not use
Note
The MAC address is on a printed label visible from the front.
