3.2.6 SIMOTION CompactFlash card
Function
The SIMOTION Kernel (SIMOTION D410-2 󹪝rmware) and the software used to control the drives
(SINAMICS 󹪝rmware) are contained on the CF card.
The CompactFlash card (CF card) is used to
• Backup technology packages and user data
• Update (e.g. SIMOTION 󹪝rmware update)
Slot for CompactFlash card
The CF card is inserted into the plug-in module over the blanking cover (see Overview of
operator control and display elements (Page 39)).
NOTICE
Impermissible use of the CompactFlash card
The CF card of the SIMOTION D410-2 must not be used in a SIMOTION D410, D4x5 or D4x5-2!
NOTICE
Elektrostatisch gefährdete Bauelemente
The CompactFlash card is an ESD-sensitive component.
De-energize the SIMOTION D410‑2 device before inserting or removing the CompactFlash
card. The SIMOTION D410‑2 is in a de-energized state when all the LEDs are OFF.
Comply with the ESD rules.
Additional information
For more information on writing and formatting the CF card, see the SIMOTION D410-2
Commissioning Manual.
Operator control (hardware)
3.2 Operator controls
SIMOTION D410-2
Equipment Manual, 07/2021, A5E33446720B 45

Siemens SIMOTION Specifications

General

Power Supply	24 V DC
Interfaces	PROFIBUS, PROFINET, Ethernet
Product type	Control Unit
Series	SIMOTION D
Display Output	VGA
