4.6.2 Interface characteristics
Table 4-16 Interface characteristics
Features Type
Connector type (X120, X121) 12-pin spring-loaded terminal
Connector type (X130, X131) 8-pin spring-loaded terminal
Number of connectable conductors 1
Connectable cable types and conductor cross-sec‐
tions
Rigid 0.2 mm² … 1.5 mm²
Flexible 0.2 mm² … 1.5 mm²
Flexible, with wire-end ferrule without plas‐
tic sleeve
0.25 mm² … 1.5 mm²
Flexible, with wire-end ferrule with plastic
sleeve
0.25 mm² … 0.75 mm²
AWG / kcmil 24 … 16
Stripped length 10 mm
Tool Screwdriver 0.4 x 2.0 mm
Max. cable length 30 m
Note
To prevent an incorrect connection, the X120, X121, X130 and X131 connectors are supplied
coded. The terminal and pin numbers are also inscribed on the connectors.
4.6.3 Interface assignment
The following tables contain the pin assignments of the onboard I/Os.
Interfaces
4.6 Digital I/Os / temperature sensor / analog input
SIMOTION D410-2
58 Equipment Manual, 07/2021, A5E33446720B
