Note
Overheating if ventilation clearances are too small
Insucient ventilation clearances result in overheating and therefore in more failures and a
shortened service life of the component.
Maintain 50 mm ventilation clearances above and below the component.
6.2 SIMOTION D410-2 DP/PN dimension drawing
Figure 6-2 SIMOTION D410-2 DP/PN dimension drawing (dimensions in mm)
Dimension drawings
6.2 SIMOTION D410-2 DP/PN dimension drawing
SIMOTION D410-2
96 Equipment Manual, 07/2021, A5E33446720B
