Note
Ground potential and housing (PE) are connected internally with low impedance.
Note
The 24 V DC cable must be approved for temperatures of up to 75 °C.
The maximum permissible cable length is 10 m.
Interface characteristics
Table 4-23 Interface X124
Features Type
Connector type 4-way screw-type terminal
Number of connectable conductors 1
Connectable cable types and conductor cross-sec‐
tions
Rigid 0.2 mm² … 2.5 mm²
Flexible 0.2 mm² … 2.5 mm²
Flexible, with wire-end ferrule without plas‐
tic sleeve
0.2 mm² … 2.5 mm²
Flexible, with wire-end ferrule with plastic
sleeve
0.2 mm² … 1.5 mm²
AWG / kcmil 22 … 12
Stripped length 6 … 7 mm
Tool Screwdriver 0.5 x 3 mm (M2.5)
Tightening torque 0.4 to 0.5 Nm (3.5 ... 4.4 lbf in)
Max. current carrying capacity, incl. loop-through 20 A (15 A per UL/CSA)
Max. cable length 10 m
Interfaces
4.7 Power supply
SIMOTION D410-2
76 Equipment Manual, 07/2021, A5E33446720B
