SIMOTION D410-2 o󹪜ers the following functions via the Ethernet interface:
• PROFINET basic services (e.g. DCP, LLDP, SNMP)
Although these PROFINET basic services provide uniform functions for the address
assignment and diagnostics, they do not provide PROFINET IO communication for the
connection of drives or I/O modules, for example.
• Communication with STEP 7 and SIMOTION SCOUT
• Communication between SIMOTION and SIMATIC NET OPC
The "SIMATIC NET SOFTNET-S7 (S7-OPC server)" software must be installed on the PG/PC for
this function.
• Connection of HMI systems
• Communication with other devices over TCP/IP or UDP communication
• IT communication (e.g. via SIMOTION IT OPC XML‑DA)
For further information on the software packages, see the SIMOTION PM 21 Catalog.
Interface characteristics
Table 4-25 X127 interface
Characteristic Type
Connector type RJ45 socket connector
Cable type Industrial Ethernet cable
Maximum cable
length
100 m
Autocrossing Yes, i.e. both crossed and uncrossed cables can be used
Blanking cover for Ethernet interface included in the scope of delivery;
blanking cover (50 units), article number: 6SL3066‑4CA00‑0AA0
Interface assignment
Table 4-26 X127 interface assignment
Representation Pin Signal name Signal type Meaning


1 TXP Output Ethernet send di󹪜erential signal
2 TXN Output Ethernet send di󹪜erential signal
3 RXP Input Ethernet receive di󹪜erential signal
4 - - Reserved, do not use
5 - - Reserved, do not use
6 RXN Input Ethernet receive di󹪜erential signal
7 - - Reserved, do not use
8 - - Reserved, do not use
Interfaces
4.8 Ethernet interface
SIMOTION D410-2
78 Equipment Manual, 07/2021, A5E33446720B

Siemens SIMOTION Specifications

General

Power Supply	24 V DC
Interfaces	PROFIBUS, PROFINET, Ethernet
Product type	Control Unit
Series	SIMOTION D
Display Output	VGA
