6.2.3 Message for a memory card that is not inserted
Function description
The converter identi󹪝es that a memory card is not inserted, and signals this state. The message
is deactivated in the converter factory setting.
Activate message
Procedure
1. Set p2118[x]=1101, x=0, 1,…19
2. Set p2119[x]=2
Message A01101 for a memory card that is not inserted is activated.
❒
To cyclically signal to the higher-level control that a memory card is not inserted, connect
parameter r9401 to the send data of the 󹪝eldbus interface.
Deactivate message
Procedure
1. Set p2118[x]=1101, x=0, 1,…19
2. Set p2119[x]=3
Message A01101 for a memory card that is not inserted is deactivated.
❒
Parameter
Parameter Explanation Factory setting
p2118[0…19] Change message type, message number 0
p2119[0…19] Change message type, type 0
r9401 Safely remove memory card status -
6.2.4 Manual upload with Startdrive
Overview
If you insert the memory card into a converter that is already supplied with power, you must start
the upload manually using a commissioning tool.
Uploading the converter settings
6.2Uploading to the memory card
SINAMICS G120C Converters
168 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C PN Specifications

General

Power range	0.55 kW to 132 kW
Control type	Vector control, V/f control
Protection class	IP20
Ambient temperature range	-10 °C to +50 °C
Product type designation	SINAMICS G120C
Integrated Safety	STO (Safe Torque Off)
Operating Temperature	-10 °C to +50 °C
Storage temperature range	-40 °C to +70 °C
Communication interfaces	PROFINET
Output voltage range	0 V to input voltage
Overload Capacity	150% for 60 s
Relative humidity	5% to 95%, non-condensing
Altitude	Up to 2000 m without derating
