You successfully replaced the converter.
❒
10.2 Downloading the converter settings
10.2.1 Converter without enabled safety functions
10.2.1.1 Automatic download from the memory card
Overview
We recommend that you insert the memory card before switching on the converter. The
converter automatically imports its settings from the inserted memory card.
Precondition
The following requirements apply:
• The converter power supply has been switched o󹪜.
• The converter settings are not protected against copying.
Download with active know-how protection with copy protection (Page401)
Function description
Procedure
1. Insert the memory card into the converter.
2. Switch on the power supply for the converter.
3. The converter loads the settings from the memory card.
4. After loading, check whether the converter outputs Alarm A01028.
– Alarm A01028:
The loaded settings are not compatible with the converter.
Delete the alarm with p0971=1.
Recommission the drive.
– No alarm A01028:
The converter accepts the settings that have been loaded.
You have transferred the settings to the converter.
❒
Corrective maintenance
10.2Downloading the converter settings
SINAMICS G120C Converters
382 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C PN Specifications

General

Power range	0.55 kW to 132 kW
Control type	Vector control, V/f control
Protection class	IP20
Ambient temperature range	-10 °C to +50 °C
Product type designation	SINAMICS G120C
Integrated Safety	STO (Safe Torque Off)
Operating Temperature	-10 °C to +50 °C
Storage temperature range	-40 °C to +70 °C
Communication interfaces	PROFINET
Output voltage range	0 V to input voltage
Overload Capacity	150% for 60 s
Relative humidity	5% to 95%, non-condensing
Altitude	Up to 2000 m without derating
