• IND, bit 8…15 (subindex): = 1 hex (CDS1 =Index 1)
• IND, bit 0…7 (page index): = 0 hex (o󹪜set 0 corresponds to 0 hex)
• PWE1, Bit 0…15: = 2D2 hex (722=2D2 hex)
• PWE2, Bit 10…15: = 3F hex (drive object - for SINAMICS G120, always 63 = 3f hex)
• PWE2, Bit 0…9: = 2 hex (Index of Parameter (DI2 =2))
3DUDPHWHUFKDQQHO
3:(KLJKUGZRUG3:(ORZWKZRUG
,1'QGZRUG
3DJHLQGH[3DUDPHWHUQXPEHU6XELQGH[3DUDPHWHUYDOXH
3.(VWZRUG
'ULYH2EMHFW,QGH[$.







Figure8-19 Telegram, to assign DI2 with ON/OFF1
Advanced commissioning
8.6Drive control via PROFIBUS or PROFINET
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 227
