 Function SINAMICS 
  G120 G120D
6 Commissioning with prede󹪝ned motor data for SIMOTICS GP/SD synchro‐
nous-reluctance motors:
• Second generation: 1FP1.04 → 1FP1.14
• Further frame sizes:
– 1.1kW … 3kW, 15001/min, 18001/min, 28101/min
– 0.75kW … 4kW, 30001/min, 36001/min
• In planning:
– 37kW … 45kW, 15001/min, 18001/min, 28101/min
– 5.5kW … 18.5kW, 30001/min, 36001/min
– 45kW, 30001/min, 36001/min
– The prede󹪝ned motor data is already included in the 󹪝rmware
✓ - ✓ - ✓
1)
- ✓ - -
7 Extended setting option for evaluating the STOP cam in the "basic positioner"
function
Two di󹪜erent functions to evaluate STOP cams can be set:
• Edge-triggered evaluation (factory setting)
• Level-triggered evaluation
For more information, refer to the "Basic Positioner" Function Manual or the
operating instructions for "SINAMICS G120D Converter with CU250D-2 Con‐
trol Units".
"Basic positioner" function manual (https://
support.industry.siemens.com/cs/ww/en/view/109477922)
Operating instructions SINAMICS G120D with CU250D-2 (https://
support.industry.siemens.com/cs/ww/en/view/109477365)
- - - - - ✓ - ✓ -
1)
Installation with PM240-2 or PM240P-2 Power Modules
Appendix
A.1New and extended functions
SINAMICS G120C Converters
452 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
