Siemens SINAMICS Intelligent Operator Panel User Manual

Options
7.2 Hand-held device
Intelligent Operator Panel (IOP)
Operating Instructions, 08/2015, FW V1.6.1, A5E00110011B AF
109
The IOP has no internal power source, so to increase the IOP's versatility, the hand-held
device has been designed.
The complete list of converters that work with the IOP are listed in Auto hotspot. The
following list comprises the converters that require the hand-held kit because the IOP cannot
be mounted directly on the converter:
● SINAMICS G120D-2 CU240D-2
● SINAMICS G120D-2 CU250D-2
● SINAMICS ET 200pro FC-2
● SINAMICS G110D
● SINAMICS G110M
● SINAMICS S110 CU305
Table 7- 1 Hand-held device order information
Order number
Item quantity
Item
Remarks
6SL3255-0AA00-4HA0
1
IOP
1 Hand-held module
1
Power supply unit
4
Rechargeable batteries
1.2 V 2100 mAh NiMH (see table below)
1
RS232 cable
3 m
Note
Battery order information
The batteries supplied with the IOP Hand
-held Kit should be replaced with exactly the same
type of batteries. The batteries that have been tested for use with the IOP are given below:
Company: GP Batteries
Order Number: GP210AAHC
Website: GP Batteries (
http://www.gpbatteries.com/INT/index.php)
The layout of the IOP hand-held device is shown in the figure below.
