6.3 Parameters
Intelligent Operator Panel (IOP)
64 Operating Instructions, 08/2015, FW V1.6.1, A5E00110011B AF
Saving & reset
This option allows the user access to all the parameters r
e-
garding the saving and reset functions of the Inverter. Each
parameter displays is currently set value and these ca
n be
modified if required.
System information
This screen displays all the parameters that contain system
information regarding the Inverter. The majority of these
pa-
rameters are read
-only and are for information purposes only.
Basic settings
Displays the effective Drive Data Set (DDS).
Each basic setting can be selected and modified if necessary.
Inputs/outputs
This option allows access to all the necessary parameters to
configure the following signa
ls:
•
Digital inputs
•
Digital outputs
•
Analog inputs
•
Analog outputs
The user can navigate through the various inputs and outputs
to see the current configuration of the inputs and outputs and,
if necessary access the parameters directly to modify their
values.
In the example screen opposite, the parameters for
the digital inputs is shown.
