Siemens SINUMERIK 808D ADVANCED

808D ADVANCED Page 13 Programming and Operating — Turning
Tool Setup
s
Content
Unit Description
This unit describes how to create and set up tools.
Unit Content
Create tool
A tool must have been created and
measured before executing the
program.
Step 1
Press “Offset” on the PPU.
Create tool
Load tool
into active
position
Measure
tool
Move
machine
with hand-
wheel
JOG
spindle
Execute M
function
Start
spindle
Create tool
edge
Test tool
offset
results
Tool edge
position
code
Press the “Tool list” SK on the PPU.
Please make sure the system is in JOG mode.
End
