09.91 3 Operating Sequences
3.1.4 Tool offset
TOOL
DATA
Press the “TOOL DATA” softkey.
The data stored in the magazine table (PLC) is displayed (the location No. is the same as the
D No. of the tool offset table). Press the “RECALL” key to return to the “TOOL OFFSET”
menu.
LIST OF
TOOLS
Press the “LIST OF TOOLS” softkey.
This display then appears on the
screen.
((Bild 810M/61 einmontieren))
NEXT
When you have pressed the “NEXT” softkey further
stored tool numbers are displayed. You cannot “PAGE
UP” in the tool table.
DISPLAY DATA
Press the “DISPLAY DATA” softkey.
The first six tool numbers stored (T number) in
accending order of location numbers.
Press the “GEOMETRY DATA” softkey to move to the “TOOL OFFSET” menu. You can
return to the standard menu by pressing the “RECALL” key twice.
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 3-15
SINUMERIK 810M, GA3 (BN)
