Siemens SINUMERIK 810M User Manual

4 Monitoring Functions 01.93
4.4 Alarm numbers and groups/delete alarms
4.4 Alarm numbers and groups/delete alarms
The alarms are divided into 7 alarm groups (5 NC and 2 PLC alarm groups)
NC alarms:
• POWER ON alarms
• RS232C (V.24) alarms
• RESET alarms/axis-specific
• RESET alarms/general
• ERASE alarms
PLC alarms:
• PLC error messages
• PLC operational messages
Tabular overview with assignment of alarm no. and clear function
Operating the
acknowledge key
Alarm cleared by ...Alarm groupAlarm number
Switching on
the control
POWER ON alarms
1 .... 15
40 ....99, 132 *
2)
1. Calling the softkey menu
including the ”DATA IN-
OUT function”
1)
2. Operating ”DATA IN-OUT
softkey”
3. Operating ”STOP
softkey”
RS232C
( V.24) alarms
16 ... 39
Operating the
RESET key
RESET alarms/axis-specific100
*
....196
*
2)
Switching on
the control
RESET alarms/axis-specific
Operating the
RESET key
RESET alarms/general2000 .... 2999
ERASE alarms3000 .... 3201
Operating the
acknowledge key
PLC error messages6000 .... 6163
The messages are reset
automatically by the PLC
PLC operational messages7000 .... 7023
1320, 1321, 1322, 1323,
1324
1) The ”DATA-IN-OUT” function can be called in the following operating modes:
AUTOMATIC / JOG / REFPOINT / INC1 ........ INC10000 / PRESET
2 ) The asterisk ” * ” stands for : ”0” = axis 1, ”1” = axis 2, ”2” = axis 3, ”3” = axis 4, ”4” = axis 5.
4-4 © Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02
SINUMERIK 810M, GA3 (BN)
