3 Operating Sequences 11.90
3.1.11 Contour
• • •
Now enter the first value using the numeric keys;
then store it using the input key.
The inverse video marking now jumps to the next
input field for the contour: the control now waits for
your next input etc.
.
.
.
Using the cursor keys, you can position the inverse
video marking to any input field, if, for example, you
wish to modify the geometry values for the selected
contour.
.
.
.
Now enter, one after the other, into all of the input fields of the contour marked in inverse
video - the rest of the geometry values - as described above.
Note:
Note the input fields marked in inverse video on the CRT display, in
curly brackets, in which there are several values (”X” and ”Y” in
example).
In this case you are only allowed to enter one value (i.e. only the X
value or the Y value, in the example).
If you have inadvertently entered two values, operate
the ”DELETE PARAMETER softkey.
DELETE
PARAM.
STORE
When you have entered all the values required for
the contour, operate the ”STORE” softkey.
The contour is now stored in the part program with all the entered values. The control
generates the ”Block End” (LF) character itself, and shows you the complete block
entered.
X
Y
...
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
...
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
3-52 © Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02
SINUMERIK 810M, GA3 (BN)
