01.93 3 Operating Sequences
3.2.8 ”Incremental´” mode (”INC FEED 1 ... INC FEED 10000”)
By operating the appropriate direction key on the
integrated machine control panel you traverse the
axis selected ...
or
... select the axis to be traversed with the axis
selector switch on the external machine control
panel ...
... and then press one of the direction keys.
Note:
The red ”Feed hold” LED display must not be
bright during the sequence of operation.
– 4
– Y
– X
+X
– Z
+Z
+4
+Y
or
5
4
Z
Y
X
+–
Note:
The direction keys can perform in two different ways:
• ”Modal”
•”Jog Operation”
When ”Modal” the axis is always traversed by one increment, in accordance with the setting
(1, 10, 100, 1000, 10000 increments), when the key is pressed (irrespective of whether the
key is pressed for a short or long time).
In ”Jog operation” the axis is traversed for as long as the key remains pressed. When the
key is no longer being pressed, the traversing movement is stopped - even if the set
increment has not been reached.
