11.90 2 Operation
2.1.2 SINUMERIK 810M operator interface with external machine control panel
This key pad enables you to jog the
axes in the ”JOG”, ”REPOS” or ”INC...”
modes.
• The ”Feed hold” LED
must not be bright
• The CRT shows the specified feedrate value ”F” at
which the axes will travel when you operate the
direction keys. The value is displayed as an absolute
value and as a ”%” of the programmed feedrate
(see Section 2.1.1.6: ”Feedrate decrease / increase”,
in this section)
• In ”JOG” the feed motion is arbitrary. The
traverse path is only limited by the end limit switch.
• In ”REPOS” the feed motion is arbitrary (see
”JOG”).
If, however, the point of interruption (in a part
program that has been partially run) is reached first,
the direction keys become inactive.
• The direction keys can traverse the axes:
– in continuous mode
– in jog mode
Continuous mode:
When the direction key is pressed (whether you press for a short
or long time), the axis only traverses one increment
(1/10/100/1000/10000 µm, depending on the setting).
Jog mode:
The axis will traverse as long as you press the direction key. Traversing stops when you
release the key. This also happens if the set increment has not been reached.
Axis selector switch with direction keys / Jogging axes
5
