Examples
4.2 Protection zones
Basic logic functions: Axis monitoring, protection zones (A3)
70 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
$SN_PA_PLUS_LIM[0] 0 ; Value of the limit in the positive direction in the 3rd
dimension
$SN_PA_MINUS_LIM[0] 0 ; Value of the limitation in the negative direction in the 3rd
dimension
$SN_PA_CONT_NUM[0] 4 ; Number of valid contour elements
$SN_PA_CONT_TYP[0,0] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for spindle chuck, contour element 0
$SN_PA_CONT_TYP[0,1] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for spindle chuck, contour element 1
$SN_PA_CONT_TYP[0,2] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for spindle chuck, contour element 2
$SN_PA_CONT_TYP[0,3] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for spindle chuck, contour element 3
$SN_PA_CONT_TYP[0,4] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 4
$SN_PA_CONT_TYP[0,5] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 5
$SN_PA_CONT_TYP[0,6] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 6
$SN_PA_CONT_TYP[0,7] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 7
$SN_PA_CONT_TYP[0,8] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 8
$SN_PA_CONT_TYP[0,9] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for spindle chuck, contour element 9
$SN_PA_CONT_ORD[0,0] -100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 0
$SN_PA_CONT_ORD[0,1] -100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 1
$SN_PA_CONT_ORD[0,2] 100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 2
$SN_PA_CONT_ORD[0,3] 100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 3
$SN_PA_CONT_ORD[0,4] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 4
$SN_PA_CONT_ORD[0,5] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 5
$SN_PA_CONT_ORD[0,6] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 6
$SN_PA_CONT_ORD[0,7] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 7
$SN_PA_CONT_ORD[0,8] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 8
$SN_PA_CONT_ORD[0,9] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 9
$SN_PA_CONT_ABS[0,0] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 0
$SN_PA_CONT_ABS[0,1] 110 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 1
