Detailed Description
2.3 Continuouspath mode, exact stop and LookAhead (B1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
69
2.3 Continuouspath mode, exact stop and LookAhead (B1)
2.3.1 Signals from channel (DB21, ...)
DB21, ...
DBX36.3
All axes stationary
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
All axes assigned to the channel are stationary with interpolator end.
No other traversing movements are active.
2.3.2 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX60.6
Position reached with exact stop coarse
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The axis is in the appropriate exact stop and no interpolator is active for the axis and:
the control is in the reset mode (reset key or end of program)
the axis was last programmed as a positioning axis or positioning spindle (initial setting of
supplementary axis: Positioning axis)
the path movement was stopped with NC Stop
the spindle is in the closed-loop positioncontrolled mode (SPCON/SPOS instruction) and is
stationary
the axis is switched from closed-loop speedcontrolled to closed-loop positioncontrolled mode
with IS "position measuring system"
Signal state 0 or
edge change
1 → 0
The axis is not in the appropriate exact stop or the interpolator is active for the axis or:
the path movement was stopped with NC Stop
the spindle is in the closed-loop speedcontrolled mode (SPCOF/SPOSA instruction)
the "followup" mode is active for the axis
the "parking" mode is active for the axis
the axis is switched from closed-loop positioncontrolled to closed-loop speedcontrolled mode
with IS "position measuring system"
Signal irrelevant for
...
Rotary axes that are programmed as rounding axes.
Corresponding to .... MD36000 $MA_STOP_LIMIT_COARSE (exact stop coarse)
