Siemens Sinumerik 840 sl Function Manual

Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
79
2.9 Mode group, channel, program operation, reset response (K1)
2.9.1 Signals to mode group (DB11)
DB11, ...
DBX0.0 AUTOMATIC mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
AUTOMATIK mode is selected by the PLC program.
Signal state 0 or
edge change
1 → 0
AUTOMATIK mode is not selected by the PLC program.
Signal irrelevant for
...
DB11, ... DBX0.4 (operating mode, changeover inhibit) = 1
Corresponding to .... DB11, ... DBX6.0 (active AUTOMATIC mode)
DB11, ...
DBX0.1 MDA mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
MDA mode is selected by the PLC program.
Signal state 0 or
edge change
1 → 0
MDA mode is not selected by the PLC program.
Signal irrelevant for
...
DB11, ... D0.4 (operating mode, changeover inhibit) = 1
Corresponding to .... DB11, ... DBX6.1 (active MDA mode)
DB11, ...
DBX0.2 JOG mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
JOG mode is selected by the PLC program.
Signal state 0 or
edge change
1 → 0
JOG mode is not selected by the PLC program.
Signal irrelevant for
...
DB11, ... DBX0.4 (operating mode, changeover inhibit) = 1
Corresponding to .... DB11, ... DBX6.2 (active JOG mode)
