Detailed Description
2.16 Feeds (V1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
137
DB21, ...
DBX25.3
Feed rate override selected for rapid traverse
Signal state 0 or
edge change
1 → 0
The feed rate override switch should not be activated as rapid traverse override switch.
Application
example(s)
The signal is used when no separate rapid traverse override switch is available.
DB 21, ...
DBX29.0 - DBX29.3
Activate fixed feed rate 1 - 4 for path/geometry axes
Edge evaluation: no Signal(s) updated: cyclic
Description These signals are used to select/de-select the function "fixed feed" and define which fixed feed
should be effective for path/geometry axes.
%LW %LW %LW %LW 0HDQLQJ
)L[HGIHHGLVGHVHOHFWHG
)L[HGIHHGLVVHOHFWHG
)L[HGIHHGLVVHOHFWHG
)L[HGIHHGLVVHOHFWHG
)L[HGIHHGLVVHOHFWHG
Corresponding to .... MD12202 $MN_PERMANENT_FEED[n]
MD12200 $MN_RUN_OVERRIDE_0
2.16.2 Signals to axis/spindle (DB31, ...)
DB31, ...
DBB0
Feed rate override (axisspecific)
Edge evaluation: no Signal(s) updated: cyclic
