Data lists
5.2 Signals
Basic logic functions: Auxiliary Function Output to PLC (H2)
64 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Number Identifier: $MC_ Description
22080 AUXFU_PREDEF_SPEC Output specification (predefined auxiliary function)
22100 AUXFU_QUICK_BLOCKCHANGE Block change without delay
22110 AUXFU_H_TYPE_INT Type of H auxiliary functions
22200 AUXFU_M_SYNC_TYPE Output timing for M functions
22210 AUXFU_S_SYNC_TYPE Output timing of S functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22230 AUXFU_H_SYNC_TYPE Output timing for H functions
22240 AUXFU_F_SYNC_TYPE Output timing of F functions
22250 AUXFU_D_SYNC_TYPE Output timing of D functions
22252 AUXFU_DL_SYNC_TYPE Output timing of DL functions
22254 AUXFU_ASSOC_M0_VALUE Additional M function for program stop
22256 AUXFU_ASSOC_M1_VALUE Additional M function for conditional stop
5.2 Signals
5.2.1 Signals to channel
DB number Byte.Bit Description
21, ... 30.5 Activate associated M01
5.2.2 Signals from channel
DB number Byte.Bit Description
21, ... 58.0 – 58.4 M function 1 - 5 change
21, ... 59.0 – 59.4 M function 1 - 5 not included in list
21, ... 60.0 - 60.2 S function 1 - 3 change
21, ... 60.4 - 60.6 S function 1 - 3 quick
21, ... 61.0 - 61.2 T function 1 - 3 change
21, ... 61.4 - 61.6 T function 1 - 3 quick
21, ... 62.0 - 62.2 D function 1 - 3 change
21, ... 62.4 - 62.6 D function 1 - 3 quick
21, ... 63.0 E function 1 change
21, ... 63.4 E function 1 quick
