Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
245
Declaration of the function
FUNCTION FC 26 : VOID
// NAME:
HPU_MCP
VAR_INPUT
BAGNo : BYTE ;
ChanNo: BYTE ;
END_VAR
BEGIN
END_FUNCTION
Description of formal parameters
The table below shows all formal parameters of the "HPU_MCP" function.
Signal Type Type Range of values Remark
BAGNo I BYTE 0 - b#16#0A
and
b#16#10 - b#16#1A
No. of mode group to which the mode signals
are transferred.
BAGNo >= b#16#10 means access to the
second machine control panel.
ChanNo I BYTE 0 - B#16#0A Channel no. for the channel signals
2.12.27.1 MCP selection signals to the user interface
Operating modes and machine functions
Source:
MCP - Key
Destination:
Interface DB (parameter ModeGroupNo)
representation for mode group 1
AUTOMATIC DB11, ... DBX0.0
MDI DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. DB11, ... DBB2, Bit 0 to 5
