Siemens Sinumerik 840 sl Function Manual

Examples
4.2 Protection zones
Basic logic functions: Axis monitoring, protection zones (A3)
74 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
$SN_PA_CONT_ORD[0,8] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_ORD[0,9] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_ORD[1,0] -190 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_ORD[1,1] -210 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 1
$SN_PA_CONT_ORD[1,2] -210 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_ORD[1,3] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_ORD[1,4] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 4
$SN_PA_CONT_ORD[1,5] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 5
$SN_PA_CONT_ORD[1,6] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 6
$SN_PA_CONT_ORD[1,7] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 7
$SN_PA_CONT_ORD[1,8] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 8
$SN_PA_CONT_ORD[1,9] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 9
$SN_PA_CONT_ABS[0,0] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 0
$SN_PA_CONT_ABS[0,1] 40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_ABS[0,2] 40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_ABS[0,3] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_ABS[0,4] -50 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_ABS[0,5] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_ABS[0,6] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_ABS[0,7] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_ABS[0,8] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_ABS[0,9] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_ABS[1,0] -50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_ABS[1,1] -30 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 1
