Detailed Description

2.9 Sum offsets and setup offsets

Basic logic functions: Tool Offset (W1)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

151

Configuration

MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4=0: (Properties of sum offset in the TO

area) default setting:

Only one set of sum offsets exists per DL number.

We refer in general to the sum offset.

This describes the data represented by $TC_SCPx.

'RIIVHW

6XPRIIVHW

6XPRIIVHW

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@

Figure 2-50 MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4 = 0

Tool T = t is active. With the data in the figure, the following is programmed:

; Cutting edge offsets, i.e., $TC_DP3 to $TC_DP11 + wear ($TC_DP12 to

$TC_DP20) + adapter dimension

...

DL=1

; Sum offset 1 is added to the previous D2 compensations, i.e., $TC_SCP13

to $TC_SCP21.

...

DL=2

; Sum offset 2 is added to the D2 compensation instead of sum offset 1, i.e.,

$TC_SCP23 to $TC_SCP31.

...

DL=0

; Deselection of sum offset;

only the data of D2 remain active.
