Detailed description
2.7 Program operation mode
Basic logic functions: Mode group, channel, program operation, reset response (K1)
104 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
The effect of commands/signals
The program status can be controlled by activating different commands or interface signals.
The following table shows the resulting program status when these signals are set
(assumption: status before the signal is set -> Program status running).
Table 2-3 Effect on program status
Commands
Program execution statuses
Aborted Interrupted Stopped Wait Running
IS "Reset" X
IS "NC Stop" X
IS "NC stop at block limit" X
IS "NC stop axes and spindles" X
IS "Read-in disable" X
IS "Feed stop, channelsp." X
IS "Feed stop, axissp." X
Feed override = 0% X
IS "Spindle stop" X
M02/M30 in a block X
M00/M01 in a block X
IS "Single block" X
IS "Delete distancetogo" X
Auxiliary functions output to PLC but
not yet acknowledged
X
Wait instruction in program X
