Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
67
:.6
(16
3B75$)5$0(3B3)5$0(
3B,62)5$0(
3B&<&)5$0(
0'0&B)5$0(B$&6B6(7
The following machine data can be used to set whether the ENS is with or without the
programmable frame, the transformation frame and $P_ISO4FRAME:
MD24030 $MC_FRAME_ACS_SET (setting of the ENS coordinate system)
As default, the value 1 is set.
Reconfiguring the SZS affects all SZS actual-value displays and the $AA_IEN[axis] system
variables. Traversing geometry axes in JOG mode in the SZS also depends on the
configuration.
