Siemens Sinumerik 840 sl Function Manual

Examples
4.1 Axes
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
143
Machine data Value
MD20070 AXCONF_MACHAX_USED[1] = 2
MD20070 AXCONF_MACHAX_USED[2] = 3
MD20070 AXCONF_MACHAX_USED[3] = 4
MD20070 AXCONF_MACHAX_USED[4] = 5
MD20070 AXCONF_MACHAX_USED[5] = 6
MD20080 AXCONF_CHANAX_NAME_TAB[0] =X
MD20080 AXCONF_CHANAX_NAME_TAB[1] =Y
MD20080 AXCONF_CHANAX_NAME_TAB[2] =Z
MD20080 AXCONF_CHANAX_NAME_TAB[3] = B
MD20080 AXCONF_CHANAX_NAME_TAB[4] = WZM
MD20080 AXCONF_CHANAX_NAME_TAB[5] = S1
MD30300 IS_ROT_AX[3] = 1
MD30300 IS_ROT_AX[4] = 1
MD30300 IS_ROT_AX[5] = 1
MD30310 ROT_IS_MODULO[3] = 1
MD30310 ROT_IS_MODULO[4] = 1
MD30310 ROT_IS_MODULO[5] = 1
MD30320 DISPLAY_IS_MODULO[3] = 1
MD30320 DISPLAY_IS_MODULO[4] = 1
MD20090 SPIND_DEF_MASTER_SPIND = 1
MD35000 SPIND_ASSIGN_TO_MACHAX[AX1] = 0
MD35000 SPIND_ASSIGN_TO_MACHAX[AX2] = 0
MD35000 SPIND_ASSIGN_TO_MACHAX[AX3] = 0
MD35000 SPIND_ASSIGN_TO_MACHAX[AX4] = 0
MD35000 SPIND_ASSIGN_TO_MACHAX[AX5] = 0
MD35000 SPIND_ASSIGN_TO_MACHAX[AX6] = 1
